The luxury wing gate adopts our company's exterior cabinet, which is novel, beautiful and uniquely shaped. It is easy to use and conducive to overall maintenance. The door body is driven by a synchronous belt. When the door-closing resistance exceeds the set value, the door body can open automatically. In case of power failure, the door body will also open automatically without the need for a battery. The intelligent gate is an intelligent access management device for non-contact channel detection and control, adopting the company's latest patented mechatronics control and drive technology. Multiple sets of sensors control the entrance and exit through the glass door wings. Authorized personnel can pass through smoothly without any obstruction and without the need for individual inspection, while unauthorized access is rejected. It provides high-quality entrance and exit control to ensure the safety of children in the park.

    This gate is suitable for parks such as kindergartens, primary schools, office buildings, and hotels. The service life and safety of the product are the primary considerations. The entire system operates with a stepless positioning device, and the operation process is controlled by sensors, with no mechanical collision, thus achieving stable operation, low noise and less wear. Based on the summary of actual usage data from numerous projects, the actual service life of the equipment is more than 5 million times. High-priced components such as magnet adsorption, belt drive, and servo mobile positioning driver are all humanized designs to avoid pinching children.

Technical Specifications

Dimensions (millimeters, mm) and Weight (kilograms, kg)

Length: 1400 mm

Width: 300 mm

Height: 980 mm

Weight: approximately 50 KG

Main materials

Cabinet: 304 stainless steel

Surface treatment: wire drawing / polishing / electroplating / baking paint

Movement: 45# steel, surface electroplated with color zinc; mechanical movement: [based on German technology] non-destructive movement

Infrared: stainless steel anti-glare metal sensor

Door body: organic glass or extra-soft rubber

Movement Performance

Transmission mode: Servo mobile positioning driver

Safety mode: Unobstructed passage after power failure

Power-assisted drive: Brushless motor

Door opening method: Center-split and double-opening

Door opening and closing speed: 0.1-999 seconds (user-adjustable)

Passage width: 550mm-600mm;

Door body stroke: 300mm (single door body)

Equipment noise: Door opening and closing ≦30db

Passing speed: 35 persons/minute in normally closed mode; 60 persons/minute in normally open mode

Control input/output: 6 channels of switch output (12V and 24V dry contact signals) / 3 channels of switch input (DC level signals with pulse width not less than 100ms, driving current not less than 10mA, and high-low level difference of 5 ~ 36V)

Relative humidity: 0 ~ 95% (non-condensing)

Movement life: 5 million times

Custom Features

◆ Material, surface treatment method, appearance style and size

◆ Integrated access control system

◆ Integrated ticketing system

◆ Integrated photography system

◆Integrated temperature control system

◆ Install remote control buttons

◆ Install LED counter (built-in or external optional)

◆ Waterproof and dustproof design: IP65

 Functional Features

• Multiple sets of infrared sensors monitor the channel status in real-time, with precise logical judgment, enabling unobstructed authorized passage.

• Four-fold protection for pedestrians in the channel, including mechanical device protection, door position detection, current detection, and channel sensor protection, to prevent pinching.

• The entire system operates with a stepless positioning device, and the operation process is controlled by sensors without mechanical impact.

• CNC machining process, fine surface treatment, and strong corrosion resistance.

• Equipped with an automatic reset function. After a pedestrian's legal verification, if they do not pass within the specified time, the system will automatically cancel the user's passage permission for this time.

• Convenient and easy to use, facilitating the passage of personal belongings such as packages and luggage.

• Anti-tailgating function: protection level 2.

• Passage mode: one-way, two-way (optional), with adjustable running speed; multiple working modes available.

• Light prompt: indication of passage direction.

• Equipped with lightning protection and leakage protection functions.

• Protection functions: anti-pinching, anti-collision, anti-blocking, anti-stall, and protection against electrical overvoltage and overcurrent.

• Prevention of illegal operations and alarm function.

• Standard external electrical interface with photoelectric safety isolation, which can be

connected to various control devices for easy system integration.

• Remote control and setting functions.

Electrical and Environmental

• Voltage: 110V to 240V AC (wide-range power input voltage)

• Frequency: Single-phase 50Hz to 60Hz

• Operating Voltage: DC24V

• Current: 300mA at static state; 4A at dynamic state (maximum operating current)

• Operating Temperature: -20 to 70°C (-4 to 158°F)

• Storage Temperature: -40 to 80°C (-40 to 176°F)

• Relative Humidity: 5% to 95% in non-condensing state

2.2 Expandable Functions:

• Bidirectional automatic counting function, which can "add" in the forward direction and "subtract" in the reverse direction, and automatically count the number of people present (customized).

• Voice prompt function: "Welcome! Have a nice trip! Please swipe your card!" etc. (customized);

• Selection of telescopic arm material and original color.

Installation Requirements

Single-phase 3A 110V to 220V AC power supply, grounded

Connecting wires to control equipment

Possible civil engineering work and fixing work

Note:

Security Level 1: Basic anti-tailgating identification system. The device is relatively short in length and meets the basic level of two-way single-person passage identification.

Security Level 2: Anti-tailgating identification system with optimal length and structure, reaching a higher level of two-way single-person passage identification, and capable of identifying children and strollers.

Security Level 3: This device uses mechanical devices and sensors installed on the machinery for two-way passage identification and tailgating control.
